Sealed Calcium Lead Acid Battery Plates Unformatted for Vrla and UPS Battery

Sealed Calcium Lead Acid Battery Plates Unformatted for Vrla and UPS Battery

Quick Details Place of Origin: Guangdon, China (Mainland) Brand Name: GOLD LIGHT POWER Model Number: 6V4Ah/12V7Ah Usage: PARTS & COMPONENTS FOR ELECTRIC ACCUMULATORS Voltage: 6V/12V Sealed Type: Sealed Maintenance Type: Free Size: +69*39*2.5/-69*39*1.65 Weight: 33g+ 21g- Nominal Capacity:...

Send Inquiry

Description

Quick Details
Place of Origin: Guangdon, China (Mainland)

Brand Name: GOLD LIGHT POWER
Model Number: 6V4Ah/12V7Ah

Usage: PARTS & COMPONENTS FOR ELECTRIC ACCUMULATORS
Voltage:   6V/12V

Sealed Type: Sealed Maintenance Type: Free
Size: +69*39*2.5/-69*39*1.65

Weight: 33g+ 21g-
Nominal Capacity: 1.8A

Plate Name: lead acid battery plate
Type: lead acid battery plate

Certificate: CE UL ISOs ROHS MSDS,etc
Warranty: 1 Year

Application:  PARTS & COMPONENTS FOR ELECTRIC ACCUMULATORS
Plates: Lead Calcium

Product name: lead acid battery plate


Packaging & Delivery
Packaging Details lead acid battery plate : cartons on pallet.

Delivery Time lead acid battery plate: 30 days after payment confirmation


Sealed Calcium Lead Acid Battery Plates Unformatted for Vrla and UPS Battery


LEAD ACID BATTERY PLATE

ells per Unit

6

Normal Voltage

12V/6V

Capacity

200Ah@20Hr-rate to 1.80V per cell@25℃

Weight

Approx.(58±3% kg) (123.46lbs)

Maximum Discharge Current

2000A(5sec)

Internal Resistance

Approx. 4.2mΩ full charged @25℃

Operating Temperature Range

Discharge: -20℃~60℃

Charge: 0℃~50℃

Storage: -20℃~60℃

Nominal Operating Temperature Range

25℃±3℃(77&℉±5&℉)

Float Charging Voltage

13.7~13.9VDC/unit Average @25℃

Maximum Charging Current

50A

Equalization and Cycle Service

14.4V~15.0VDC/unit Average @ 25℃

Self Discharge

GOLD LIGHT POWER Valve Regulated Lead Acid (VRLA) batteries can be stored

for more than 6 months at 25℃. Self-discharge ratio less than 3%

per month at 25℃. Please charge batteries before using.

Terminal

lead

Container Material

ABS(UL94-HB)

*Flammability resistance of (UL94-V0) can be available upon request


Our company has introduced a series of advanced equipment including automatic laminating machine, automatic welding machine and so on. In addition, we have obtained ISO9001 quanlity management system certification, ISO14001 environmental management system certification and ISO18001 certification. We have also obtained the until stats UL approval and EU CE approval for all type of batteries. Our products range consist of more than 200 categories, which extensive using Alarm Systems, Power Tools, Electric vehicles, Electric toy, Motorcycles, UPS Power Systems, Solar Energy etc.. The nominal voltage of GOLD LIGHT POWER battery including 2V, 4V, 6V, 8V, 12V, 24V, etc. The rated capacity is from 0.3AH-3000AH. Products are exported to Southeast of Asia, Middle east, Africa, Europe, American and others countries and regions.


More information, please feel free to contact with us.
If there is anything we can do for you, we shall be more than pleased to do so.
